Strip Morphologies 001







-Parametric exploration; manipulation of polyline control points.

Tags:

Categories: Modelling

Author:jonbailey

studying: architecture design

Subscribe

Connect with archimorph and help grow the network.

3 Comments on “Strip Morphologies 001”

  1. Quetzalcoatl
    December 14, 2011 at 6:16 am #

    Hi Jon,

    I’ve seen this in the grasshopper3d site. Can you explain how you have done this amazing thing!

    My email is: qetzalcoatl@hotmail.com

    Thank you!
    Fran!

  2. December 14, 2011 at 9:36 am #

    Hello Fran,

    This was actually a very simple definition that uses a system of attraction to manipulate the control points of lines. Whether attracted by points, curves, surfaces (representing wind flow, solar radiation, etc.), lines are rebuilt based on their “attraction” to those values. Once the curves are rebuilt, the new polylines are then lofted to the original lines.

    • Quetzalcoatl
      December 15, 2011 at 4:38 am #

      Thank you for the answer Jon! I’m trying to do some wind architecture and this images inspire me so much! If you want, you can see my definition for modify a surface based on a wind vector: http://www.grasshopper3d.com/forum/topics/wind-find-forming

      it’s a first aproximation, but the wind test works ;). I have the problem with the surface modification.

      Best Regards,
      Fran!
